3 products
1970-74 Firebird/Trans Am Power Rack Only
Product# 8011100-01
Regular price $925.00 Save $-925.00For this Pontiac kit we used a front steer, center take-off style rack and pinion made to match the original center-link of these cars. The rack and pinion match the stock front suspension for great handling, responsiveness, and no bump steer! The rack comes mounted to a one piece bracket which bolts up to the same factory holes on the frame that held the steering box and idler arm.
We did our first install on a 455, and we used Dynomax Headers (Their Part #86104). Other headers may work, but might require modifications.
|
Tech Info: |
Kit Includes: |
| Pinion Type / Size: | 3/4"-36 Spline | Rack & Pinion |
| Amount of Travel: | 6.75" | Mounting Bracket |
| Turns Lock to Lock: | 3 Turns | Mounting Hardware |
| Pressure Port Size: | 18mm - 6 AN Banjo (lower) | |
| Return Port Size: | 16mm - 6 AN Banjo (upper) | |
| Pump Required: | High Flow / Pressure | |
| Inner End Threads: | 11/16"-18 Female | |
| Outer ends: | Reuse Originals | Click here to view installation instructions. |
1975-81 Firebird/Trans Am Power Rack and Pinion Kit
Product# 8011110-01-01
Regular price $1,820.00 Save $-1,820.00For this Pontiac kit we used a front steer, center take-off style rack and pinion made to match the original center-link of these cars. The rack and pinion match the stock front suspension for great handling, responsiveness, and no bump steer! The rack comes mounted to a one piece bracket which bolts up to the same factory holes on the frame that held the steering box and idler arm.
We did our first install on a 455, and we used Dynomax Headers (Their Part #86104). Other headers may work, but might require modifications.
|
Tech Info: |
Kit Includes: |
| Pinion Type / Size: | 3/4"-36 Spline | Rack & Pinion |
| Amount of Travel: | 6.75" | Mounting Bracket |
| Turns Lock to Lock: | 3 Turns | Pump & Line Kit |
| Pressure Port Size: | 18mm - 6 AN Banjo (lower) | Steering Shaft Kit |
| Return Port Size: | 16mm - 6 AN Banjo (upper) | Mounting Hardware |
| Pump Required: | High Flow / Pressure | |
| Inner End Threads: | 11/16"-18 Female | |
| Outer ends: | Reuse Originals | Click here to view installation instructions |
1975-81 Firebird/Trans Am Power Rack Only
Product# 8011170-01
Regular price $1,150.00 Save $-1,150.00For this Pontiac kit we used a front steer, center take-off style rack and pinion made to match the original center-link of these cars. The rack and pinion match the stock front suspension for great handling, responsiveness, and no bump steer! The rack comes mounted to a one piece bracket which bolts up to the same factory holes on the frame that held the steering box and idler arm.
We did our first install on a 455, and we used Dynomax Headers (Their Part #86104). Other headers may work, but might require modifications.
|
Tech Info: |
Kit Includes: |
| Pinion Type / Size: | 3/4"-36 Spline | Rack & Pinion |
| Amount of Travel: | 6.75" | Mounting Bracket |
| Turns Lock to Lock: | 3 Turns | Mounting Hardware |
| Pressure Port Size: | 18mm - 6 AN Banjo (lower) | |
| Return Port Size: | 16mm - 6 AN Banjo (upper) | |
| Pump Required: | High Flow / Pressure | |
| Inner End Threads: | 11/16"-18 Female | |
| Outer ends: | Reuse Originals | Click here to view installation instructions. |
